상세 정보 |
|||
| 이름: | 질소 공기 분리 장치 | 청정: | 90%~ 99.9999% |
|---|---|---|---|
| 이슬점: | -45 more 이상 | 재료: | 스테인레스 스틸 또는 탄소강 |
| 용량: | 5nm3/hr ~ 5500nm3/hr | 압력: | 조절할 수 있는 |
| 강조하다: | compact nitrogen air separation unit,PSA nitrogen generator for chemical factory,100SCFM nitrogen gas generator |
||
제품 설명
| Attribute | Value |
|---|---|
| Name | Nitrogen Air Separation Unit |
| Purity | 90%~99.9999% |
| Dew point | -45℃ or more |
| Material | Stainless steel or carbon steel |
| Capacity | 5Nm3/hr~5500Nm3/hr |
| Pressure | Adjustable |
Our 100SCFM Compact Size Nitrogen Air Separation Unit is designed to provide a reliable, continuous nitrogen supply for chemical factories, delivering purity up to 99.99%. Utilizing advanced Pressure Swing Adsorption (PSA) or membrane separation technology, it efficiently separates nitrogen from compressed air at a flow rate of 100SCFM, meeting high-demand industrial requirements. The compact design integrates compressor, dryer, filtration, and control systems into a space-saving, skid-mounted unit for easy installation and operation. Fully automatic, energy-efficient, and low-maintenance, this nitrogen generator ensures safe, cost-effective, and consistent nitrogen delivery, supporting chemical processes that require high-purity, uninterrupted nitrogen supply.
| Model | Nitrogen flow rate(Nm3/hr) | Purity(%) | Air need(m3/min) | Net dimensions(mm) |
|---|---|---|---|---|
| KRN159 | 7 | 99 | 0.33 | 1200*600*1900 |
| 6 | 99.5 | 0.32 | ||
| KRN219 | 15 | 99 | 0.7 | 1200*600*1900 |
- Online monitoring of oxygen purity, pressure, flow rate and dew point.
- Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying.
- Air dryer and air filters automatic drainer discharge.
- Automatic warning of spare parts replacement.
- Remote control / fully automatic
- Molecular sieve automatic compaction
- Pneumatic valve switching by programmable controller automatic control
- The IPC, DCS, the specific configuration of other specific programs
